Technical data

Overview of air permeability values

	0.5 Pa (cross ventilation low wind)	1.0 Pa (cross ventilation strong wind)	1.5 Pa (fan-supported ventilation)
basic equipment	approx. 4 m3/h	approx. 6 m3/h	approx. 8 m3/h
complete equipment	approx. 11 m3/h	approx. 17 m3/h	approx. 21 m3/h
complete equipment with increased gap dimension (by 2 mm)	approx. 17 m3/h	approx. 26 m3/h	approx. 32 m3/h





The air permeability values from the table have to be added to the air permeability values of the door undercut.



Door undercut air permeability values in accordance with DIN 1946-6

	0,5 Pa	1,0 Pa	1,5 Pa
m3/h	0.23 x length (cm) x height (cm)	0.32 x length (cm) x height (cm)	0.4 x length (cm) x height (cm)
